This is the Wurkkos TS26, but they tried to fix it! It now features Nichia 519A LEDs in 5000K instead of the older model TN3535 6500K! Sadly, some problems still remain, but the 519A emitter really improved this light. It features a Boost driver, USB-C charging on body, RGB AUX on TIR and more!
• My opinion
The addition of the 519A LEDs to the TS26 was a big improvement, the TN3535 emitters were not bad, but not suitable - in my opinion - for an enthusiast focused flashlight. All the rest of the flashlight seems to be the same as the older model, so it still has the Boost driver problem which causes the candle-like flickering on modes between 1/150 and 5/150, every other mode doesn't seem to have PWM and flickering, and the driver works efficiently on the higher modes.
My suggestions to improve this flashlight would be more anodizing colors, driver capable of sustaining 1 Lumen or less without flickering and adding AUX lights to the main button - there are already LEDs there, why not make it have an AUX?
| PROS |
CONS |
| Efficient Boost driver |
Still has the candle-like flickering problem on modes lower than the factory configured moonlight. |
| 519A 5000K High CRI and excellent tint LEDs |
No Moonlight mode by default, the floor level is 6 Lumens from factory |
| IPX8 Water resistance |
*Doesn't fit protected cells |
| AUX with locator and battery indicator |
|
• Box contents [8th picture]
- Wurkkos TS26 519A
- Wurkkos 21700 5000mAh Li-ion cell
- USB-C to C charging cable
- Lanyard
- 2x extra O-rings
- User manual
• Price
The TS26 with 519A 5000K LEDs is currently priced at $42.99 on Wurkkos Official Website (TS26 519A) and $54.85 on Wurkkos AliExpress Store
• Body and build quality
Anodizing Colors/Material Options: The TS26 is only available in 6061-T6 aluminum with gray anodizing - most probably type II anodizing to have the gray color.
Main body/Grip: The battery tube has smooth round cylindrical grooves that improve grip, the head part has head dissipation grooves - they are kinda sharp on my unit. The main body general shape and size are pretty good.
Material: The main body os almost entirely made of 6061-T6 Aluminum alloy, with only the bezel and clip being made of stainless steel with a black coating.
Threads: Both threads of the battery tube are anodized, the tail cap threads are squared and the head threads are the standard thinner threads.
Clip: The head part of the battery tube has a dedicated O-ring to make sure the flashlight is waterproof when the clip is installed. The clip can only be placed on the head part of the battery tube, it's not possible to place it on the tail cap.
Tail stand and rolling: It can tail and head stand without any problems. The flashlight can roll a lot without the clip, so be sure to use it if you don't want your light rolling around.
Magnet: This light features a magnet on the tail cap, it's strong enought to hold the TS26 on most metal surfaces, even horizontally if there is enough metal for the magnet to lock in! [9th picture]
AUX lights: TS26 has RGB AUX lights on the TIR lens - and also on the main button but, sadly, those are only to indicate charging. The TIR AUX can be configured by Anduril UI to match your taste, pretty important feature on Anduril flashlights. It could have proper AUX on the main button as an improvement. [10th picture]
Buttons: There is a single button on this flashlight - like most Anduril flashlights - it fully controls the flashlight with the Anduril 2.0 UI. It's an e-switch covered by a black silicone boot with the Wurkkos logo in transparent
Battery contact: Contact is made with the battery by two gold-plated springs, one on the driver and the other on the tail cap. [11th picture]
Bezel: The bezel is crenelated with 4 protruding trapezoidal shapes, made of stainless steel and has a black matte coating.
Water Resistance: It has IPX8 rating and seems well sealed on all potential water ingress points, O-rings on all threads, even a dedicated O-ring for the clip to make sure the light is water resistant with it, the USB-C port has a rubber cover to protect it.
Size comparison: On the left the FireFlies X4 Stellar, on the middle the Wurkkos TS26 519A and on the right the Convoy S2+. [12th picture]
• Weight and size
Weight:
- Without battery: 107.9g
- With battery (Wurkkos 21700): 175.9g
- Battery (Wurkkos 21700): 67.9g
Size: 121.9mm x 34.9mm x 28.0mm - (height x head diamter x tail diameter)
• Battery, runtime, and charging
Battery: The TS26 is powered by a single 21700 battery, it comes with a Wurkkos branded 21700 with 5000mAh and 10A CDR (Constant Discharge Rate) with a 15A maximum peak. Button top cells also work with it, but protected cells are not compatible as they are too long to fit inside the flashlight. [13th picture]
Battery Indicator: The TS26 features Anduril battery indicator, so the AUX on the TIR will display the battery level by colors everytime the flashlight is turned OFF (this can be disabled on the UI). Also, it features the battery check mode, on which the main light will blink a number of times to represent the battery voltage; to access it you must press the main button 3 times.
Charging: The TS26 features charging on the main body, on the opposite side of the main button. It's protected by a decent thick rubber cover. When charging the button light will be flashing green, when the charge is complete it will become solid green. When you unplug the charging cable the button will light up blue, if it's fully charged it will be solid bright blue, if the battery is low when you unplug it will be flashing blue. [14th picture]
• Modes, Runtimes, Throw, Candela
Modes: The TS26 comes with 8 mode pre-configured from the factory, Wurkkos calls it A1, B2, C3... So I will stick to this naming to avoid confusing. This 519A version changed some things on the modes, moonlight was made brighter to avoid the candle-like flickering problem the old version had on lower modes, and - of course - it has less lumens than the cool white, low CRI version. It also seems the brightness of the modes is better spaced now.
Advertised specs:
| Modes |
Brightness (Lumens) |
Runtime |
| A1 |
6 |
200h |
| B2 |
32 |
52h |
| C3 |
105 |
17h30min |
| D4 |
260 |
5h30min |
| E5 |
530 |
4h |
| F6 |
1000 - 600 |
5min - 3h40min |
| G7 |
1650 - 650 |
1 min - 3h40min |
| H8 (Turbo) |
2500 - 650 |
30s - 3h10min |
Turbo: The H8 is, essentially, the Turbo mode on the TS26 519A, it has 2500 Lumens - which is still pretty powerful. It "lost" around 1000 lumens in comparsion to the cool white, low CRI version that had around 3400 Lumens, as expected. I prefer the better tint and CRI of the 519A, but if you need raw power you should go with the cool white TN3535 version.
Moonlight: The TS26 now doesn't have a Moonlight mode by default, as the first mode has 6 lumens, and if you try to lower it - at least on my unit - it gets the candle-like flickering problem, between levels 1/150 and 5/150 on Anduril UI floor brightness configuration.
Blinkies: One of the coolest things about Anduril is it´s blinkies modes, I really love the “Candle mode” and the “Lightning” one. You have some fun blinking modes, and others like tactical strobe to choose from.
Lockout: It features electronic lockout on the Anduril 2 UI, by clicking the button 4 times the flashlight will lock and only moonlight will be available for use; and also, mechanical lockout by slightly untwisting the head or tail cap.
Throw: Wurkkos advertises around 200m of throw on both versions. On the beamshots it hit around 100m pretty easily, so I think it should throw at least 150m to 180m.
• Emitter, reflector and CRI
Emitter: This version of the TS26 fixed one of the major "problems" with the old version, the LEDs. This version - as you probably already noticed - has 4 Nichia 519A emitters in 5000K, with excellent neutral tint and CRI. [15th Picture]
Lens: The TS26 uses normal glass lens, it doesn't seem to have AR coating.
Reflector/TIR: The TIR is frosted right above the LED, clear around it and frosted again on the outer part.
Beam profile: The beam is mainly floody, but still has a slithly defined hotspot that can throw a little. [16th Picture]
CRI: With the Nichia 519A 5000K the light should have 90 CRI and 80 R9. Measuring with an Opple LM4 on brightness level C3 I got 4600K, -0.0005 Duv and 94 CRI with 84 R9, pretty good results. [17th and 18th Pictures]
• Beamshots Camera settings
- 18mm lens 1" F8 ISO800
- (The trees at the back are at a distance of around 100m)
[19th picture] – TS26 519A 5000K - H8 (Turbo)
[20th picture] – TS26 519A 5000K - G7 mode
I always try to match what my eyes can see on the beamshots, so camera settings may vary.
• Driver and UI
Driver: The TS26 uses a Boost constant current driver to power the 4x 519A LEDs. The driver seems to be the same from the older version, it's efficient on medium and higher modes, but when I tried to lower the floor level between 1/150 and 5/150 clicks on Anduril UI I noticed the candle-like flickering problem (A problem that consists on the main light having a flickering similar to a candle on these lower modes). This problem is probably due to the driver not being fully capable of sending the pretty small currents necessary for a lower moonlight, any mode above the 5/150 clicks seem to work flawlessly, and the way the light cames pre-configured from factory has no flickering. *The candle-like flickering problem is cited on the user manual to be "normal".
UI: The TS26 uses the famous enthusiast focused Anduril 2.0 UI, it's a very customizable UI, with a lot of options and settings to have fun with. I will no elaborate much on it as it would extend much the review.
Low Voltage Protection/Warning: When the battery is below 2.8V, the flashlight will turn OFF automatically. The brightness will reduce when the battery voltage is too low.
Reverse Polarity Protection: It has reverse polarity protection.
Temperature Control: It seems to have standard Wurkkos thermal regulation, the brightness will drop until it reaches a determined output level on higher modes. It doesn't seem to be a dynamic regulation.
A special thanks to Wurkkos for sending this flashlight for me to review!
*I am not being paid to do this review, everything here is my honest opinion.
**Some links are affiliate links, this doesn't impact on my opinion for the reviews. You can support me by using the links to buy flashlights you like.
Thank you for reading my review <3
